MT9D111 Camera Module

Features

• Ultra-low power consumption, progressive scan
• 200 million pixels resolution (1600 H x 1200 V)
• 1/3.2 inch optical format
• frame rate up to 15 fps under full resolution
• Real-time JPEG encoding
• Integrated with processor, with much flexibility
• Many automatic functions including correcting or enhancing images, and fast exposure adjustment
• Integrated 10-bit ADC chip
• Support ITU_R BT.656 (YCbCr), 565RGB, 555RGB, 444RGB and original output data format
• Support JPEG 4:2:2 and 4:2:0 output

Parameter

• Response rate: 1.0 V / lux-sec (550nm)
• Master Clock: 6 MHz-80 MHz (integrated PLL)
• Signal to noise ratio: > 41dB (max)
• Power supply voltage: 2.5v-3.1V
• Power consumption: < 150mW (@ 30 fps)

You can download document below, including sample code, datasheet and schematic.

Click here to download the document
